GE Frame 5 (MS5001) Power Barge Gas Turbine Units, approx. 20 MW, 60 Hz
Used, built 1972, approx. 13,800 to 18,100 fired hours, some units require completion work
+84 386 456 619
GE Frame 5 (MS5001) gas turbine generator units mounted on power barges, used, 60 Hz.
Technical data
- Gas turbine: GE MS5001 (Frame 5)
- Output: approx. 20 MW per unit (site rating approx. 15.8 to 19.4 MW in summer, 21.5 to 23.9 MW in winter)
- Voltage / frequency: 13.8 kV, 60 Hz
- Step-up transformers: 160 MVA, 13.2 kV to 138 kV
- Fuel: diesel; 12-inch natural gas connection per technical notes
- Year of manufacture: 1972
- Fired hours: approx. 13,800 to 18,100 per unit
- Combustion: lean-head-end combustors
- Starter: Cummins KTA19
- Controls: Petrotech PLC and HMI (2017), DECS 400 excitation, black-start capable
- Inspections: borescope 2020, GE TIL 1576 rotor end-of-life inspections completed
- Status: barge-mounted; some units require completion work
- Price: on request
LKS 360 acts as an independent broker. The equipment belongs to its owner and is offered on the owner's behalf, subject to prior sale. Full technical documentation to qualified buyers after LOI and proof of funds.
Contact: WhatsApp +49 170 4656619 · manager@lks360.com
